HD-5002
# Dual channel direct coupled amplifier.
# Rugged and most reliable. A new benchmark for professionals requiring a sonically superior high power amplifier.
# Class H operation for superior sound quality.
- Need Help? Chat Now!
| SPECIFICATIONS | HD-5002 |
|---|---|
| CONTINUOUS RATED POWER | 2 OHM : 2500W+2500W RMS 4 OHM : 2000W+2000W RMS 8 OHM : 1500W+1500W RMS |
| TOTAL HARMONIC DISTORTION | <0.5%@8Ω 1KHz 1/5Po |
| OUTPUT CIRCUITRY | Class H |
| FREQUENCY RESPONSE | 5Hz-20KHz ±1dB |
| INPUT SENSITIVITY | 0.775V/1.0/1.4V |
| INPUT IMPEDANCE BALANCED | 20KΩ / 10KΩ |
| COOLING | 4 AC FAN |
| DIMENSIONS | 3U , 19” RACK MOUNTING |
| WEIGHT | 30Kg |
