NT-3.0
# Dual channel direct coupled amplifier.
# Rugged and most reliable. A new benchmark for professionals requiring a sonically superior high power amplifier.
# Class AB operation for superior sound quality.
- Need Help? Chat Now!
| SPECIFICATIONS | NT-3.0 |
|---|---|
| CONTINUOUS RATED POWER | 2 OHM : 1500W+1500W RMS 4 OHM : 1000W+1000W RMS 8 OHM : 750W+750W RMS |
| CLASS | AB |
| POWER CONSUMPTION | 3200VA @240V/50Hz |
| THD + N | 0.5% |
| FREQUENCY RESPONSE (-1dB) | 20-20,000Hz |
| POWER BANDWIDTH (0.5% THD) | 20-20,000Hz |
| INPUT SENSITIVITY | 0dB (775mV) & 4dBm (1.23V) |
| INPUT IMPEDANCE | 10k Unbalanced, 20k Balanced |
| DAMPING FACTOR | 400:1 (8 OHM) |
| INPUT EQUALISER | Inbuilt Dual Crossover |
| PROTECTION | Temprature, Short Circuit, Overload etc |
| INPUT CONNECTORS | 2 x XLR, STEREO PHONE JACK 6.3 mm |
| OUTPUT CONNECTORS | Speakon 4-Way, Heavy Duty Binding Post |
| COOLING | 2 AC FAN |
| DIMENSIONS | 3U , 19” RACK MOUNTING |
| WEIGHT | 30Kg |
