SSA-5000 BT
500 WATTS, AC & 36V DC Operation
# 7 Mic & 3 Aux Inputs.
# Preamplifier and line output for connecting to a booster amplifier and recording the programme.
# Line input for connecting the output from any external mixer or permitting other to be used as a booster power amplifier.
# Resettable circuit breaker for protection against overload and short circuit.
# Instant transfer to DC power (Car Battery) if AC power fails.
- Need Help? Chat Now!
| SPECIFICATIONS | SSA-5000 BT |
|---|---|
| POWER OUTPUT | 700W Max., 500W RMS at 10% THD, 450W RMS at 5% THD |
| OUTPUT REGULATION | <2dB, no load to full load at 1kHz |
| INPUT CHANNELS | 7 × Mic 0.6mV/4.7kΩ, 2 × Aux 100mV/470kΩ |
| 1 × Aux 250mV/50kΩ, 1 × Line 1Ω/50kΩ | |
| FREQUENCY RESPONSE | 50–15,000Hz ±/−3dB |
| SIGNAL TO NOISE RATIO | 60dB |
| TONE CONTROLS | BASS: ±10dB at 100Hz, Treble: ±10dB at 10kHz |
| OUTPUTS | LINE 1V/1kΩ |
| SPEAKER OUTPUTS | 4Ω, 8Ω, 70V & 100V |
| POWER SUPPLY | AC: 220–240V 50/60Hz — DC: 36V (3×12V Car battery) |
| POWER CONSUMPTION | AC: 1000VA — DC: 8A |
| DIMENSION | W510 × H172 × D385 mm |
| WEIGHT | 25kg |
